窒素ガリウム
Gallium Nitride (GaN) : Physics, Devices, and Technology (Devices, Circuits, and Systems)

  • 提携先の海外書籍取次会社に在庫がございます。通常3週間で発送いたします。
    重要ご説明事項
    1. 納期遅延や、ご入手不能となる場合が若干ございます。
    2. 複数冊ご注文の場合は、ご注文数量が揃ってからまとめて発送いたします。
    3. 美品のご指定は承りかねます。

    ●3Dセキュア導入とクレジットカードによるお支払いについて
  • 【入荷遅延について】
    世界情勢の影響により、海外からお取り寄せとなる洋書・洋古書の入荷が、表示している標準的な納期よりも遅延する場合がございます。
    おそれいりますが、あらかじめご了承くださいますようお願い申し上げます。
  • ◆画像の表紙や帯等は実物とは異なる場合があります。
  • ◆ウェブストアでの洋書販売価格は、弊社店舗等での販売価格とは異なります。
    また、洋書販売価格は、ご注文確定時点での日本円価格となります。
    ご注文確定後に、同じ洋書の販売価格が変動しても、それは反映されません。
  • 製本 Hardcover:ハードカバー版/ページ数 388 p.
  • 言語 ENG
  • 商品コード 9781482220032
  • DDC分類 621.38152

Full Description

Addresses a Growing Need for High-Power and High-Frequency Transistors

Gallium Nitride (GaN): Physics, Devices, and Technology offers a balanced perspective on the state of the art in gallium nitride technology. A semiconductor commonly used in bright light-emitting diodes, GaN can serve as a great alternative to existing devices used in microelectronics. It has a wide band gap and high electron mobility that gives it special properties for applications in optoelectronic, high-power, and high-frequency devices, and because of its high off-state breakdown strength combined with excellent on-state channel conductivity, GaN is an ideal candidate for switching power transistors.

Explores Recent Progress in High-Frequency GaN Technology

Written by a panel of academic and industry experts from around the globe, this book reviews the advantages of GaN-based material systems suitable for high-frequency, high-power applications. It provides an overview of the semiconductor environment, outlines the fundamental device physics of GaN, and describes GaN materials and device structures that are needed for the next stage of microelectronics and optoelectronics. The book details the development of radio frequency (RF) semiconductor devices and circuits, considers the current challenges that the industry now faces, and examines future trends.

In addition, the authors:




Propose a design in which multiple LED stacks can be connected in a series using interband tunnel junction (TJ) interconnects
Examine GaN technology while in its early stages of high-volume deployment in commercial and military products
Consider the potential use of both sunlight and hydrogen as promising and prominent energy sources for this technology
Introduce two unique methods, PEC oxidation and vapor cooling condensation methods, for the deposition of high-quality oxide layers

A single-source reference for students and professionals, Gallium Nitride (GaN): Physics, Devices, and Technology provides an overall assessment of the semiconductor environment, discusses the potential use of GaN-based technology for RF semiconductor devices, and highlights the current and emerging applications of GaN.

Contents

GaN High-Voltage Power Devices. AlGaN/GaN High-Electron-Mobility Transistors Grown by Ammonia Source Molecular Beam Epitaxy. Gallium Nitride Transistors on Large-Diameter Si (111) Substrate. GaN-HEMT Scaling Technologies for High-Frequency RF and Mixed Signal Applications. Group III-Nitride Microwave Monolithically Integrated Circuits. GaN-Based Metal/Insulator/Semiconductor-Type Schottky. Hydrogen Sensors. InGaN-Based Solar Cells. III-Nitride Semiconductors: New Infrared Intersubband Technologies. Gallium Nitride-Based Interband Tunnel Junctions. Trapping and Degradation Mechanisms in GaN-Based HEMTs.
